Industrial Automation Specialists are responsible for designing, improving, and supporting systems in manufacturing and process plants. They work with Industrial Automation devices like Programmable Logic Controllers (PLC), Distributed Control Systems (DCS), Supervisory Controls (SCADA), Industrial Ethernet Switches (IES), Human-Machine Interfaces (HMI), variable frequency motor drives (VFD), and a wide variety of networked actuators, sensors, and other IIOT. Most of these devices can be connected with Industrial Ethernet copper and fiber cables running a variety of industrial protocols like ProfiNET, EtherNet/IP, Modbus-TCP, EtherCAT, and CC-Link. When something goes wrong in a process, the Controls Engineer or Industrial Electrician is often called in to determine if the problem is related to control logic, devices, or the Industrial Ethernet cable between devices. Controls Engineers support a wide variety of equipment and processes and need tools to determine if problems are in the network cable, the devices, or device configurations. Click here to learn more about our Industrial Ethernet Cabling resources.
Isolating Industrial Ethernet Problems
Customers tell us that over 50% of Industrial Ethernet network problems are related to the cable (copper or fiber). Cables are sometimes made wrong, are too long, poorly terminated, susceptible to corrosion, vibration, and electrical noise.
Machines stop working or on lights indicate a problem. Network diagnostics and link LEDs usually indicate roughly where the problem is, but do not isolate the issue to a specific device, device configuration or cable.
The most common method to isolate a problem is trial and error. Basically, replace items until the problem clears. This method is time-consuming, especially when the machine stops intermittently.
Intermittent Problems - EMI
Electromagnetic Interference (EMI) generated by Variable Frequency Drives (VFD), motors, contactors, and solenoids are not supposed to disrupt Industrial Ethernet data frames (also called packets). Industrial Ethernet cables are supposed to be immune to this noise and not let EMI damage data frames. However, not all cables are made for this environment, are damaged, or maybe installed wrong. Moisture, vibration, and temperature changes can also cause weak cables to fail intermittently.
In one recent example, a material handling line with 20 VDFs stop when one particular VFD was turned on. After three days of analysis, it was determined that the VFD was operating correctly, but a short cable routed near the VFD output cable had a defect that caused ~10% of the ethernet frames to have errors when the motor was running.
Commissioning a New Machine
The Industrial Automation network is one of many elements that can delay the installation of a new machine or cause downtime during the acceptance period. Often copper and fiber optic cables are installed and not tested at all. When the machine does not work or stops working after a while (especially in an EMI environment), the engineers and installers have to troubleshoot for every possible problem. If they tested the cables and eliminated any cable problems, they would significantly reduce the about of troubleshooting and commission their system faster.
