What are the numbers in the ( )? - DTX CableAnalyzer

DTX CableAnalyzer™ 2014-02-25

New to Version 1.1 (Current Version is 2.78) for the DTX CableAnalyzer is a change in the format of the results screen:

TIA Cat 6 Permanent Link

The numbers in the brackets represent the worst margin of all pair combinations for that test parameter. If we were to look at the individual results for NEXT, we would see:

NEXT Individual Result

The smallest margin of the 12 possible combinations of NEXT is 5.1 dB, the value in the brackets on the result screen above.
